FC 302 P400 P500 P560
High/Normal load* HO NO HO NO HO NO
Typical shaft output at 550 V [kW] 315 400 400 450 450 500
Typical shaft output at 575 V [HP] 400 500 500 600 600 650
Typical shaft output at 690 V [kW] 400 500 500 560 560 630
Enclosure IP21 E1 E1 E1
Enclosure IP54 E1 E1 E1
Enclosure IP00 E2 E2 E2
Output current
Continuous (at 550 V) [A] 429 523 523 596 596 630
Intermittent (60 s overload) (at 550 V) [A] 644 575 785 656 894 693
Continuous (at 575/690 V) [A] 410 500 500 570 570 630
Intermittent (60 s overload) (at 575/690 V)
[A]
615 550 750 627 855 693
Continuous KVA (at 550 V) [KVA] 409 498 498 568 568 600
Continuous KVA (at 575 V) [KVA] 408 498 498 568 568 627
Continuous KVA (at 690 V) [KVA] 490 598 598 681 681 753
Maximum input current
Continuous (at 550 V) [A] 413 504 504 574 574 607
Continuous (at 575 V) [A] 395 482 482 549 549 607
Continuous (at 690 V) [A] 395 482 482 549 549 607
Max. cable size, line power, motor and load
share [mm
2
(AWG)
1)
]
4x240 (4x500 mcm) 4x240 (4x500 mcm) 4x240 (4x500 mcm)
Max. cable size, brake [mm
2
(AWG)
1)
]
2x185 (2x350 mcm) 2x185 (2x350 mcm) 2x185 (2x350 mcm)
Max. external electrical fuses [A]
2)
700 900 900
Estimated power loss at 600 V [W]
3) 4)
4795 6010 6493 7395 7383 8209
Estimated power loss at 690 V [W]
3) 4)
4970 6239 6707 7653 7633 8495
Weight, enclosure IP21, IP54 [kg] 263 272 313
Weight, enclosure IP00 [kg] 221 236 277
Efficiency
4)
0.98
Output frequency 0–500 Hz
Heatsink overtemp. trip
230 °F [110 °C]
Power card ambient trip
185 °F [85 °C[
* High overload=160% torque during 60 s, Normal overload=110% torque during 60 s.
Table 4.9 Technical Specifications, E-frame 525–690 V Line Power Supply 3x525–690 V AC
1) American Wire Gauge.
2) For fuse ratings, see chapter 7.2.1 Fuses.
3) Typical power loss is at normal conditions and expected to be within
±
15% (tolerance relates to variety in voltage and cable conditions.) These
values are based on a typical motor efficiency (IE/IE3 border line). Lower efficiency motors add to the power loss in the adjustable frequency drive.
If the switching frequency is raised from nominal, the power losses rise significantly. LCP and typical control card power consumptions are
included. Options and customer load can add up to 30 W to the losses, though usually a fully loaded control card and options for slots A and B
each add only 4 W.
4) Measured using 16.5 ft. [5 m] shielded motor cables at rated load and rated frequency.
