FC 302 P355
High/Normal load* HO NO
Typical shaft output at 550 V [kW] 315 355
Typical shaft output at 575 V [HP] 400 450
Typical shaft output at 690 V [kW] 355 450
Enclosure IP21 E1
Enclosure IP54 E1
Enclosure IP00 E2
Output current
Continuous (at 550 V) [A] 395 470
Intermittent (60 s overload) (at 550 V) [A] 593 517
Continuous (at 575/690 V) [A] 380 450
Intermittent (60 s overload) (at 575/690 V) [A] 570 495
Continuous KVA (at 550 V) [KVA] 376 448
Continuous KVA (at 575 V) [KVA] 378 448
Continuous KVA (at 690 V) [KVA] 454 538
Maximum input current
Continuous (at 550 V) [A] 381 453
Continuous (at 575 V) [A] 366 434
Continuous (at 690 V) [A] 366 434
Max. cable size, line power, motor and load share [mm
2
(AWG)
1)
]
4x240 (4x500 mcm)
Max. cable size, brake [mm
2
(AWG)
1)
]
2x185 (2x350 mcm)
Max. external electrical fuses [A]
2)
700
Estimated power loss at 600 V [W]
3) 4)
4424 5323
Estimated power loss at 690 V [W]
3)
4)
4589 5529
Weight, enclosure IP21, IP54 [kg] 263
Weight, enclosure IP00 [kg] 221
Efficiency
4)
4)
0.98
Output frequency 0–500 Hz
Heatsink overtemp. trip
230 °F [110 °C]
Power card ambient trip
185 °F [85 °C[
* High overload=160% torque during 60 s, Normal overload=110% torque during 60 s.
Table 4.8 Technical Specifications, E-frame, 525–690 V Line Power Supply 3x525–690 V AC
1) American Wire Gauge.
2) For fuse ratings, see chapter 7.2.1 Fuses.
3) Typical power loss is at normal conditions and expected to be within
±
15% (tolerance relates to variety in voltage and cable conditions.) These
values are based on a typical motor efficiency (IE/IE3 border line). Lower efficiency motors add to the power loss in the adjustable frequency drive.
If the switching frequency is raised from nominal, the power losses rise significantly. LCP and typical control card power consumptions are
included. Options and customer load can add up to 30 W to the losses, though usually a fully loaded control card and options for slots A and B
each add only 4 W.
4) Measured using 16.5 ft. [5 m] shielded motor cables at rated load and rated frequency.
Selection
Design Guide
MG34S222 Danfoss A/S © Rev. 2014-02-10 All rights reserved. 71
4 4
