Attaching Reader to Host Setup
Product Reference Guide
7
Attaching/Detaching the Stand
The reader can be removed or attached to the stand simply by snapping on
or off. To attach, align the holes on the bottom of the scanner with the
posts on the stand and push down to snap in place. To remove, just pull
straight up to detach the reader from the stand.
For product dimensional information, see Technical Specifications on page 263
and GPS4400 Dimensions on page 269.
Attaching/
Detaching
the Stand
The stand can also be mounted to a stationary surface using two screws.
See
Appendix G, Screw Mounting Template
for a full-scale template that
shows screw placement.
