Datalogic Gryphon GPS4421 User Manual

Data Editing References
Product Reference Guide 251
Character Conversion
Character conversion is an eight byte configuration item. The eight bytes
are 4 character pairs represented in hexadecimal ASCII values. The first
character in the pair is the character that will be converted. The second
character in the pair is the character to convert to. If the character to con-
vert in a pair is FF, then no conversion is
done.
For example, if you have the character conversion configuratio
n item set to
the following: 41423132FFFFFFFF
The first pair is 4142 or AB (41 hex is an ASCII capital
A, 42 hex is an ASCII
capital B) and the second pair is 313
2 or 12 (31 hex is an ASCII 1, 32 is an
ASCII 2). The other two pairs are FFFF and FFFF.
With the label, AB12BA21, it would look as follows after the character con
-
version: BB22BB22.
The A characters were converted to B characters and the 1 characters were
co
nver
ted to 2 characters. Nothing is done with the last two character pairs,
since they are all FF.
To set Character Conversion:
1. Go to page 59 and scan the ENTER/EXIT bar code.
2. Scan the “Configure Character Conversion” bar code.
3.
Determine the desired string. Sixteen positions must be determined as
in the
above example. Next, turn to the ASCII Chart on the inside back
cover of this manual and find the equivalent hex digits needed to
fulfill
the string.
4. Turn to Appendix D, Keypad and scan the bar codes representing the hex
characters determined in the previous step.
5. Scan the ENTER/EXIT bar code to exit Programming Mode.
If less than the expected string of 16 characters are selected, scan the
ENTER/EXIT bar code twice to accept the selections and exit Program-
ming Mode.
