Datalogic Laser Sentinel User Manual

INSTRUCTION MANUAL 127
APPENDIX D
GLOSSARY
NAME DESCRIPTION
Active opto-electronic
protective device
responsive to diffuse
reflection (AOPDDR)
A device whose sensing function is performed by optoelectronic
emitting and receiving elements. These detect the diffuse reflec
-
tion of optical radiations generated within the device by an
object located in a detection zone (specified in two dimensions).
Application Type
The configuration’s classification according to the visibility of the
parameters. It can be:
• Expert - it contains the whole set of parameters, regardless
of the device use.
• Vertical - it requires the user to insert the reference points
parameter.
Default values are provided for all interface parameters.
Demo Configuration
A configuration’s classification according to the visibility of the
parameters. Demo Configuration is made only for demonstra
-
tion purposes and the User has to insert only a Safety Area and
a Warning Area.
Catalogue
A list of all the available models of safety laser scanner and the
start point for an Offline configuration. User will use a configu
-
ration wizard in the Offline mode.
Coding
The combination of Area Switch input codes to determine zone
sets. The input code must respect the hamming distance.
Configuration
The whole set of parameters that determine the device behav-
ior. It can be classified according to the visibility of the configu-
ration parameter:
• Horizontal
• Vertical
The device configuration contains the whole set of parameters.
If the User is not able to set them, the interface will provide
default values.
By showing devices positioning, the classification based on
topology helps the User draw a Safety or a Warning Zone.
Configuration Validator
A feature used in DLSentinel to verify complete configuration
correctness.
Specific Warnings will display incorrect configuration parame-
ters.
Detection Capability
The minimum size of a detectable object by a device. This
parameter can be set for a Safety Zone and a Warning Zone of
each Area.
