DEVICE MAINTENANCE
114 SAFERY LASER SCANNER
FAST REPLACEMENT
Fast replacement allows the user to quickly replace a Master or Slave device or a Mem-
ory Group when these have suffered irreparable damage (see
Chapter 9, Diagnostics).
NOTE
This procedure can be performed on field to restore normal operation and device con-
figuration if the replacement parts have the exact same part number as the replaced
ones.
NOTE
All instructions are shown on the device display and all tasks can be completed using
the
keypad, except when the instructions refer to the DLSentinel graphic user interface.
The following paragraphs illustrate the procedure for the most common cases of Fast
R
eplacement.
Fast Replacement of the Memory Group
When the Memory Group must be replaced on an already configured Master device,
follow the procedure below:
1. unmount the damaged Memory Group and connect the new one (see
Chapter 5,
Memory Group Unmounting for Cable Connection);
2. check Memory Group model compatibility. If the model is not compatible, the
de
vice display will show the “MG NO MATCHING” message;
3. the Master device and the Memory Group topologies will not match with each
oth
er because the Memory Group has no configuration saved on board. The Mas-
ter device display will show the “INTF18” err
or message. This is a normal behavior;
4. the Memory Group can now be aligned with the Master device topology either
with a ba
ckup configuration copied from the Master device to the Memory Group
or with a configuration via DLSentinel. Select the preferred procedure using the
keypad.
In case of a backup configuration, follow the procedure shown on the Master
de
vice display. For a configuration via DLSentinel, refer to the DLSentinel User’s
Manual.
The user is recommended to contact Datalogic Technical Support before
performing Fast Replacement to assess the severity of the damage.
WARNING
This procedure must be performed by authorized personnel only.
If the replacement parts have a different part number than the replaced
ones, a new configuration via DLSentinel graphic user interface is needed.
WARNING
At the end of Fast Replacement, the user must confirm the successful com-
pletion of the procedure by checking that the safety conditions have been
restored and by validating the new part.
