WINDOW REPLACEMENT
INSTRUCTION MANUAL 105
Window Replacement Procedure
After establishing that the replacement of the optical window is necessary and after
making sure that all above-mentioned prerequisites are met, start the window replace-
ment procedure.
The new optical window package contains the following parts:
• 1 optical window;
•1 seal;
•4 Tuflok® screws.
NOTE
1. Place the Safety Laser Scanner on an even base in a controlled, pollution-reduced
en
vironment.
2. Remove the four screws fixed on the damaged optical window.
CAUTION
When handling the new optical window, avoid contaminating it with finger-
prints, dirt, scratches, dust, and polluting agents. It is recommended to
wear clean, thin gloves to unpack and install the new window.
Always disconnect power to the Safety Laser Scanner before starting the
window replacement procedure.
