LASER SENTINEL STAND ALONE MODEL
INSTRUCTION MANUAL xv
LASER SENTINEL STAND ALONE MODEL
1
2
3
4
5
6
7
8
1. Laser scanner window
2. Display
3. LED Indicators
4. Ethernet Connector
5. Keypad
6. I/O Connector (8 poles)
7. Device Class and Warning Labels
8. Direct Mounting Holes (2)
Figure 3 - Stand Alone model
