Datalogic Laser Sentinel User Manual

MECHANICAL MOUNTING
34 SAFERY LASER SCANNER
ROLL ANGLE ADJUSTMENT
NOTE
Rotate the brackets to reach the desired roll angle within the allowed range (+/-8.5 °)
and then tighten the M4 Roll Adjusting Screws (5) (1.4 - 1.5 N/m Torque).
Figure 8 - Roll Angle Adjustment
The roll angle adjustment is a procedure related only to SLS-BRACKET-A.
