Datalogic Laser Sentinel User Manual

INSTRUCTION MANUAL 27
CHAPTER 5
MECHANICAL MOUNTING
For mechanical mounting, the Laser Sentinel has two different procedures depending
on the operation necessities. The two mounting possibilities are:
• direct mounting, OR
• angle adjustment bracket mounting (if the pitch and the roll angles need to be
adjus
ted).
Optionally, the protection bracket can be added to applications using the angle adjust-
ment brackets.
NOTE
Required tool adjustable torque driver with 3 mm hex bit.
