MX-E Series Hardware Guide M610 and M610C
95 Datalogic S.r.l.
M610 and M610C
This camera line captures a 640 by 480 pixel size image with square pixels. It can partially scan the image horizontally
and vertically.
M610 and M610C Specifications
Part Number 959932001, 959932002
Pick-up Device Global Shutter CCD - 640 (H) x 480 (V) pixels
Sensor Size 1/3” (6.1 mm) diag - 4.88mm (H) x 3.66mm (V)
Capture Rate 125 full-resolution fps; higher with partial scan
Pixel Size 7.4 x 7.4 micrometers
Gain 0% to 18%
Shutter Open 10 to 1,000,000 microseconds
M610 Spectral Response (excludes lens and light source characteristics)
M610C Spectral Response (excludes lens and light source characteristics)
