Datalogic MX-E Series User Manual

MX-E Series Hardware Guide E193, E193C
79 Datalogic S.r.l.
E193, E193C
This camera captures a 2048 x 1536 pixel size image with square pixels. It can partially scan the image horizontally and
vertically.
E193 Specifications
Part Number 959933042; 959933043
Pick-up Device Global Shutter CMOS - 2048 (H) x 1536 (V) pixels
Sensor Size 1/1.8 (8.9 mm) diag - 7.07mm (H) × 5.30mm (V)
Capture Rate 36 full-resolution fps; higher with partial scan
Pixel Size 3.45 x 3.45 micrometers
Gain 0 to 360
Shutter Open 112 to 1,000,000 microseconds
Software Version Impact Software Release 11.10.0.70 or greater
E193 Spectral Response (excludes lens and light source characteristics)
