Datalogic MX-E Series User Manual

MX-E Series Hardware Guide E181, E181C
77 Datalogic S.r.l.
E181, E181C
This camera captures a 1920 x 1200 pixel size image with square pixels. It can partially scan the image horizontally and
vertically.
E181 Specifications
Pick-up Device Global Shutter CMOS - 1920 (H) x 1200 (V) pixels
Sensor Size 2/3” (11 mm) diag - 9.2mm (H) × 5.8mm (V)
Capture Rate 50 full-resolution fps; higher with partial scan
Pixel Size 4.8x 4.8 micrometers
Gain 100% to 1023%
Shutter Open 112 to 1,000,000 microseconds
Software Version Impact Software Release 11.12.0 or greater
E181 Spectral Response (excludes lens and light source characteristics)
