Datalogic MX-E Series User Manual

MX-E Series Hardware Guide Baumer Cameras
65 Datalogic S.r.l.
Baumer Cameras
Model numbers that include a “C” are color cameras.
Baumer Camera Connection
Refer to the Baumer TXG User's Guide for Gigabit Ethernet Cameras for wiring diagrams and other technical specifica-
tions.
Model
(GigE)
Resolution
(Megapixels)
Horizontal
Image Vertical FPS
(approx)
Minimum Software
Version Required
TXG02 - TXG02c .3 656 494 140 11.5.0
TXG03 - TXG03c .3 656/656 494/490 90 11.5.0
TXG04 - TXG04c .3 656/656 494/490 56 11.5.0
TXG04h .3 640 480 210 11.5.0
TXG06 - TXG06c .4 776/776 582/578 64 11.5.0
TXG08 - TXG08c .8 1032/1032 776/772 28 11.5.0
TXG12 - TXG12c 1.3 1296 996 32 11.5.0
TXG13 - TXG13c 1.4 1392/1384 1040/1036 20 11.5.0
TXG14 - TXG14c 1.4 1392/1384 1040/1036 20 11.5.0
TXG14f - TXG14cf 1.4 1392/1384 1040/1036 30 11.5.0
TXG20 - TXG20c 2.0 1624/1624 1236/1232 16 11.5.0
TXG50 - TXG50c 5.0 2448 2050 15 11.5.0
