Datalogic MX-E Series User Manual

MX-E Series Hardware Guide M180, M180C
83 Datalogic S.r.l.
M180, M180C
This camera captures a 1628 by 1236 pixel size image with square pixels. It can partially scan the image horizontally and
vertically.
M180 Specifications
Part Number 601-0357; 601-0384
Pick-up Device Progressive Scan CCD - 1628 (H) x 1236 (V) pixels
Sensor Size 1/1.8" (8.992 mm) diag - 7.16mm (H) × 5.44 mm (V)
Capture Rate 20 full-resolution fps; higher with partial scan
Pixel Size 4.4 x 4.4 micrometers
Gain 100% to 1023%
Shutter Open 31 to 1,000,000 microseconds
Exposure Start Delay 34.50 μsec
Software Version Impact Software Release10.0 or greater
M180 Spectral Response (excludes lens and light source characteristics)
