Datalogic MX-E Series User Manual

MX-E Series Hardware Guide M570 camera
93 Datalogic S.r.l.
M570 camera
This camera captures a 4096 pixel width image with a maximum line rate of 26khz.It is a monochrome, GigE line scan
camera with the following specifications.
M575 camera
This camera captures a 6144 pixel width image with a maximum line rate of 17khz.It is a monochrome, GigE line scan
camera with the following specifications.
M580 camera
This camera captures a 8192 pixel width image with a maximum line rate of 12khz.It is a monochrome, GigE line scan
camera with the following specifications.
M570 Specifications
Sensor Size 4096 pixels
Capture Rate 26,000 lines per second maximum
Pixel Size 7 x 7 micrometers
Power +12 to +24 VDC provided by 6-pin camera cable (4 Watts maximum)
Maximum Frame Height 7147 Pixels
Software Version Impact Software Release 11.2.1.11 or greater
M575Specifications
Sensor Size 6144 pixels
Capture Rate 17,000 lines per second maximum
Pixel Size 7 x 7 micrometers
Power +12 to +24 VDC provided by 6-pin camera cable (4.5 Watts maximum)
Maximum Frame Height 4765 Pixels
Software Version Impact Software Release 11.8.0.97 or greater
M580 Specifications
Sensor Size 8192 pixels
Capture Rate 12,000 lines per second maximum
Pixel Size 7 x 7 micrometers
Power +12 to +24 VDC provided by 6-pin camera cable (4.5Watts maximum)
Maximum Frame Height 3573 Pixels
Software Version Impact Software Release 11.8.0.97 or greater
