Datalogic MX-E Series User Manual

MX-E Series Hardware Guide M195, M195C
85 Datalogic S.r.l.
M195, M195C
This camera captures a 2048 by 2048 pixel size image with square pixels. It can partially scan the image horizontally and
vertically.
M195 Specifications
Part Number 601-0456; 601-0457
Pick-up Device CMOS - 2048 (H) x 2048 (V) pixels
Sensor Size 1" (15.92mm) diag - 11.26 mm (H) x 11.26 mm (V)
Capture Rate 25 full-resolution fps; higher with partial scan
Pixel Size 5.5 x 5.5 micrometers
Gain 100% to 1023%
Shutter Open 31 to 1,000,000 microseconds
Exposure Start Delay 34.50 μsec
Software Version Impact Software Release10.5.0 or greater
M195 Spectral Response (excludes lens and light source characteristics)
