SVS-Vistek Cameras (non-IP67 rated) MX-E Series Hardware Guide
Datalogic S.r.l. 70
SVS-Vistek Cameras (non-IP67 rated)
The following SVS-Vistek camera models are supported:
• eco and eco2 series
All monochrome models
All color models up to five Mpixel
• evo and hr series
All Monochrome models up to 16 Mpixel (NOT the 29 Mpixel camera)
All color models up to 5 Mpixel
Dual Ethernet connection NOT SUPPORTED. We only support a single Ethernet connection so our frame rate may
be less than the SVS-Vistek spec.
evo and hr model cameras have dual Ethernet ports to support two Gigabit/sec image rates. The MX processors and
IMPACT software do not support dual Ethernet connections, so the frame rate on these cameras may be lower than the
frame rate published by SVS-Vistek.
MX_frame_rate = min (camera_spec, 125,000,000/(width*height))
Only the camera Ethernet connector furthest from the Hirose connector will work with the MX-E processor. If you con-
nect a camera to the other connector, Impact will connect to the camera, but you cannot capture images and the error mes-
sage “Image Capture Timeout” will be written in the system log.
IMPORTANT: This section applies only to SVS-Vistek camera without an IP67 rating. For IP67 rated cameras (model
ending in 67), see “SVS-Vistek Cameras (IP67 rated)” on page 73.
Model Resolution
(Megapixels)
Color Image
Horizontal
Image Vertical FPS
(approx)
Minimum Software
Version Required
eco204MVGE
eco204CVGE
<1 No
Yes
1024 768 47 10.4.0
10.5.0
eco267MVGE
eco267CVGE
1.3 No
Yes
1360 1024 25 10.4.0
10.5.0
eco274MVGE
eco274CVGE
1.9 No
Yes
1600 1200 25 10.4.0
10.5.0
eco285MVGE
co285CVGE
1.3 No
Yes
1360 1024 34 10.4.0
10.5.0
eco414MVGE
eco414CVGE
<1 No
Yes
640 480 125 10.4.0
10.5.0
eco415MVGE
eco415CVGE
<1 No
Yes
782 494 86 10.4.0
10.5.0
eco424MVGE
eco424CVGE
<1 No
Yes
640 480 124 10.4.0
10.5.0
eco445MVGE
eco445CVGE
1.2 No
Yes
1280 960 30 10.4.0
10.5.0
eco618MVGE
eco618CVGE
<1 No
Yes
640 480 160 10.4.0
10.5.0
