Datalogic MX-E Series User Manual

E198, E198C MX-E Series Hardware Guide
Datalogic S.r.l. 80
E198, E198C
This camera captures a 2448 x 2048 pixel size image with square pixels. It can partially scan the image horizontally and
vertically.
E198 Specifications
Part Number 959933044; 959933045
Pick-up Device Global Shutter CMOS - 2448 (H) x 2048 (V) pixels
Sensor Size 2/3” (11.1 mm) diag - 8.4 mm (H) x 7.1 mm (V)
Capture Rate 22.7 full-resolution fps; higher with partial scan
Pixel Size 3.45 x 3.45 micrometers
Gain 100% to 1023%
Shutter Open 112 to 1,000,000 microseconds
Software Version Impact Software Release 11.10 or greater
E198C Spectral Response (excludes lens and light source characteristics)
