Hardware Components MX-E Series Hardware Guide
Datalogic S.r.l. 2
Hardware Components
The major hardware components of the system are the MX-E Series Processor, camera, and cables.
NOTE: All descriptions and specifications apply to all models unless otherwise noted.
• MX-E20-2-P-1, 2-camera capable, PNP outputs
• MX-E20-2-N-1, 2-camera capable, NPN outputs
• MX-E40-2-P-1, 2-camera capable, PNP outputs
• MX-E40-2-N-1, 2-camera capable, NPN outputs
• MX-E40-4-P-1, 4-camera capable, PNP outputs
• MX-E40-4-N-1, 4-camera capable, NPN outputs
• MX-E80-2-P-1, 2-camera capable, PNP outputs
• MX-E80-2-N-1, 2-camera capable, NPN outputs
• MX-E80-4-P-1, 4-camera capable, PNP outputs
• MX-E80-4-N-1, 4-camera capable, NPN outputs
• For details about MX-E Series cables, see “Processor Cables” on page 107.
• For details about MX-E Series cameras, see “Camera Specifications” on page 75.
Safety Precautions
Warning: There are no user-serviceable parts inside the hardware. To avoid electrical shock, never open the case.
Modifying or tampering with internal components will void the product warranty.
Attention: Il n'y a aucune pièce réparable par l'utilisateur à l'intérieur du dispositif. Pour éviter un choc électrique,
n'ouvrez jamais le cas. Modification ou manipulation des composants internes annulera la garantie du produit.
1. Read all of the following instructions before setting up your system. Save this document for later use.
2. Follow all warnings and instructions in this manual and in other user guides shipped with your hardware compo-
nents.
3. To avoid damage to the vision system and its components, never plug in or unplug a cable when the power is on.
Always shut down the processor and turn off the power supply before you make cable changes (see “Turning Off
the System” on page 3).
