M150, M150C MX-E Series Hardware Guide
Datalogic S.r.l. 82
M150, M150C
This camera captures a 1296 by 966 pixel size image with square pixels. It can partially scan the image horizontally and
vertically.
Shutter Open 24 to 1,000,000 microseconds
Exposure Start Delay 31.72 μsec
Software Version Impact Software Release10.3.0 or greater
M150 Specifications
Part Number 601-0352; 601-0379
Pick-up Device Progressive Scan CCD - 1296 (H) x 966 (V) pixels
Sensor Size 1/3” (6 mm) diagonal - 4.80mm (H) × 3.60mm (V)
Capture Rate 30 full-resolution fps; higher with partial scan
Pixel Size 3.75 x 3.75 micrometers
Gain 100% to 1023%
Shutter Open 22 to 1,000,000 microseconds
Exposure Start Delay 34.50 μsec
Software Version Impact Software Release10.0 or greater
M110 Specifications
M150 Spectral Response (excludes lens and light source characteristics)
