M190, M190C MX-E Series Hardware Guide
Datalogic S.r.l. 84
M190, M190C
This camera captures a 2048 by 1088 pixel size image with square pixels. It can partially scan the image horizontally and
vertically.
M190 Specifications
Part Number 601-0454; 601-0455
Pick-up Device CMOS - 2048 (H) x 1088 (V) pixels
Sensor Size 2/3" (12.749 mm) diag - 11.26 mm (H) × 5.98mm (V)
Capture Rate 50 full-resolution fps; higher with partial scan
Pixel Size 5.5 x 5.5 micrometers
Gain 100% to 1023%
Shutter Open 31 to 1,000,000 microseconds
Exposure Start Delay 34.50 μsec
Software Version Impact Software Release10.5.0 or greater
M190 Spectral Response (excludes lens and light source characteristics)
