MX-E Series Hardware Guide Turning Off the System
3 Datalogic S.r.l..
4. Never use the system if a power cable has been damaged. Do not allow anything to rest on a power cable and keep
them away from traffic.
5. The air inlets and exhausts on the unit are for ventilation. Do not block or cover these openings or insert anything
into these openings.
6. Do not expose the vision system to moisture, rain, or snow, and do not use it near water. If a component gets wet
unplug it immediately.
7. To avoid injury, never open the case. Modifying or tampering with internal components will void the product war-
ranty.
Service Personnel Only - Caution: Risk of explosion if battery is replaced by an incorrect type. Dispose of used
batteries according to battery maker’s instructions.
Turning Off the System
Warning: Turning off the processor power before stopping VPM and the Windows operating system can damage
the processor and corrupt vision programs and other system files.
Processor Turn Off Procedure
1. If any cameras are online, turn them offline.
2. Close all open vision programs.
3. Disconnect VPM from any connected cameras.
4. Close VPM.
5. Click the Windows Start menu.
6. Click Shut down.
7. Wait approximately 30 seconds for the disk access and other processor functions to stop.
8. If the processor does not power off automatically, press and release the power button on the front of the processor
(see “Front Panel Connections” on page 8).
