Datamax E-Class Mark II Programmer's Manual

Extended System-Level Command Functions
Class Series 2 Programmer’s Manual 97
(SP) Serial Port – This command configures the serial communication port(s) as
follows:
Table 5-12: Serial Port Configuration Set Command

For EX2 models the data length, parity, and stop bits are fixed at 8, N, and 1
respectively. And, for Applicator Interface Card-equipped models, this command is
also used to configure the GPIO Auxiliary port (ID always “B”).
Example: <STX>KcSPAPB;SPApN;SPAD8;SPAS1;SPAB19<CR>
The example above configures Serial Port A to use hardware and software
handshaking, an eight-bit word, with no parity and one stop bit at 19,200 bits per
second.
Value Serial Port Range / Interpretation
xyz
Where: x = Port Identifier:
y = Function: z = Setting
P - Handshaking
Protocol B - both
H - hardware
N - none
S – software
p - Parity E - even
N - none
O – odd
D - Data Length 7 - eight bits
8 - seven bits
A - Serial A
B - Serial B
S - Stop Bits 1 - one bit
2 - two bits
xyzz
Where: x = Port Identifier:
y = Function: zz = Setting:
A - Serial A
B - Serial B
B - Baud Rate 12 - 1200
24 - 2400
48 - 4800
96 - 9600
19 - 19200
28 - 28800
38 - 38400
57 - 57600
15 - 115200

Datamax E-Class Mark II Specifications

General

Resolution	203 dpi (8 dots/mm) or 300 dpi (12 dots/mm)
Operating Temperature	40°F to 95°F (4°C to 35°C)
Storage Temperature	-40°F to 140°F (-40°C to 60°C)
Print Method	Direct Thermal / Thermal Transfer
Max Print Speed	6 inches per second (ips)
Memory	8 MB DRAM
Interface	Serial, Parallel, USB
Media Type	Labels, Tags, Receipts
Media Width	0.75" (19 mm) to 4.65" (118 mm)
Media Thickness	0.0025 to 0.008 inches (0.0635 to 0.2032 mm)
Power Requirements	100-240 VAC, 50-60 Hz
