Datamax E-Class Mark II Programmer's Manual

Appendix C – Available Fonts
178 Class Series 2 Programmer’s Manual
Font sizes are dependent upon the print head resolution of the printer used. The tables
below contain a listing of the font sizes by resolution with dimensions given in dots.
Font Height Width Spacing Point Size
Font 0 7 5 1 2.5
Font 1 13 7 2 4.6
Font 2 18 10 2 6.4
Font 3 27 14 2 9.6
Font 4 36 18 3 12.8
Font 5 52 18 3 18.4
Font 6 64 32 4 22.7
Font 7 32 15 5 11.3
Font 8 28 15 5 9.9
Table C-2: Font Sizes @ 203 DPI Resolution
Font Height Width Spacing Point Size
Font 0 10 7 1 2.4
Font 1 19 10 3 4.6
Font 2 27 15 3 6.5
Font 3 40 21 3 9.6
Font 4 53 27 4 12.7
Font 5 77 27 4 18.5
Font 6 95 47 6 22.8
Font 7 47 22 7 11.3
Font 8 41 22 7 9.8
Table C-3: Font Sizes @ 300 DPI Resolution
Font Height Width Spacing Point Size
Font 0 14 10 2 2.5
Font 1 26 14 4 4.6
Font 2 36 20 4 6.4
Font 3 54 28 4 9.6
Font 4 72 36 6 12.8
Font 5 104 36 6 18.4
Font 6 128 64 8 22.7
Font 7 64 30 10 11.3
Font 8 56 30 10 9.9
Table C-4: Font Sizes @ 406 DPI Resolution

Datamax E-Class Mark II Specifications

General

Resolution	203 dpi (8 dots/mm) or 300 dpi (12 dots/mm)
Operating Temperature	40°F to 95°F (4°C to 35°C)
Storage Temperature	-40°F to 140°F (-40°C to 60°C)
Print Method	Direct Thermal / Thermal Transfer
Max Print Speed	6 inches per second (ips)
Memory	8 MB DRAM
Interface	Serial, Parallel, USB
Media Type	Labels, Tags, Receipts
Media Width	0.75" (19 mm) to 4.65" (118 mm)
Media Thickness	0.0025 to 0.008 inches (0.0635 to 0.2032 mm)
Power Requirements	100-240 VAC, 50-60 Hz
