Datamax E-Class Mark II Programmer's Manual

Appendix R – Line Mode
294 Class Series 2 Programmer’s Manual
<STX>L
PG
SG
D11
15110000160001099999999999999999999999999999999999
U
151100001200010FIXED FIELD #1
15110000080001099999999999999999999999999999999999
U
151100000400010FIXED FIELD #2
15110000000001099999999999999999999999999999999999
U
Q0001
sCDMXFRM
To print a label, the attached device now only has to send the data. Sample data in this
example is as follows:
TEST DATA AAAAAAAAAAAAAAAAAAAAAAAAA[CR]
TEST DATA BBBBBBBBBBBBBBBBBBBBBBBBB[CR]
TEST DATA CCCCCCCCCCCCCCCCCCCCCCCCC[CR]
The sample data will print the following label (layout and font are approximations):
TEST DATA AAAAAAAAAAAAAAAAAAAAAAAAA
FIXED FIELD #1
TEST DATA BBBBBBBBBBBBBBBBBBBBBBBBB
FIXED FIELD #2
TEST DATA CCCCCCCCCCCCCCCCCCCCCCCCC
If multiple labels are needed, data for the labels can be sent at the same time. Sample data
for two labels:
TEST DATA AAAAAAAAAAAAAAAAAAAAAAAAA[CR]
TEST DATA BBBBBBBBBBBBBBBBBBBBBBBBB[CR]
TEST DATA CCCCCCCCCCCCCCCCCCCCCCCCC[CR]
TEST DATA DDDDDDDDDDDDDDDDDDDDDDDDD[CR]
TEST DATA EEEEEEEEEEEEEEEEEEEEEEEEE[CR]
TEST DATA FFFFFFFFFFFFFFFFFFFFFFFFF[CR]
The sample data will print the following two labels (layout and typeface are
approximations):

Datamax E-Class Mark II Specifications

General

Resolution	203 dpi (8 dots/mm) or 300 dpi (12 dots/mm)
Operating Temperature	40°F to 95°F (4°C to 35°C)
Storage Temperature	-40°F to 140°F (-40°C to 60°C)
Print Method	Direct Thermal / Thermal Transfer
Max Print Speed	6 inches per second (ips)
Memory	8 MB DRAM
Interface	Serial, Parallel, USB
Media Type	Labels, Tags, Receipts
Media Width	0.75" (19 mm) to 4.65" (118 mm)
Media Thickness	0.0025 to 0.008 inches (0.0635 to 0.2032 mm)
Power Requirements	100-240 VAC, 50-60 Hz
