Datamax E-Class Mark II Programmer's Manual

Appendix R – Line Mode
Class Series 2 Programmer’s Manual 295
Label 1:
TEST DATA AAAAAAAAAAAAAAAAAAAAAAAAA
FIXED FIELD #1
TEST DATA BBBBBBBBBBBBBBBBBBBBBBBBB
FIXED FIELD #2
TEST DATA CCCCCCCCCCCCCCCCCCCCCCCCC
Label 2:
TEST DATA DDDDDDDDDDDDDDDDDDDDDDDDD
FIXED FIELD #1
TEST DATA EEEEEEEEEEEEEEEEEEEEEEEEE
FIXED FIELD #2
TEST DATA FFFFFFFFFFFFFFFFFFFFFFFFF
Sample Template 2:
If a template in the form of DMXFRMxx is used, the data must be preceded by the value of
xx. Below is a sample template for DMXFRMxx:
<STX>L
PG
SG
D11
15110000160001099999999999999999999999999999999999
U
151100001200010FIXED FIELD NUMBER ONE
15110000080001099999999999999999999999999999999999
U
151100000400010FIXED FIELD NUMBER TWO
15110000000001099999999999999999999999999999999999
U
Q0001
sCDMXFRMA1
Sample data for DMXFRMxx type templates:
A1>TEST DATA AAAAAAAAAAAAAAAAAAAAAAAAA[CR]
A1>TEST DATA BBBBBBBBBBBBBBBBBBBBBBBBB[CR]
A1>TEST DATA CCCCCCCCCCCCCCCCCCCCCCCCC[CR]

Datamax E-Class Mark II Specifications

General

Resolution	203 dpi (8 dots/mm) or 300 dpi (12 dots/mm)
Operating Temperature	40°F to 95°F (4°C to 35°C)
Storage Temperature	-40°F to 140°F (-40°C to 60°C)
Print Method	Direct Thermal / Thermal Transfer
Max Print Speed	6 inches per second (ips)
Memory	8 MB DRAM
Interface	Serial, Parallel, USB
Media Type	Labels, Tags, Receipts
Media Width	0.75" (19 mm) to 4.65" (118 mm)
Media Thickness	0.0025 to 0.008 inches (0.0635 to 0.2032 mm)
Power Requirements	100-240 VAC, 50-60 Hz
