Datamax E-Class Mark II Programmer's Manual

Appendix S – RFID Overview
298 Class Series 2 Programmer’s Manual
UHF Interface
This interface allows the Host Application to perform specific operations pertaining to
UHF-type tags. Since these commands override the printer’s database by interfacing
directly to the tag module, knowledge of UHF protocols and their operation is required.
See the <STX>KuR and <STX>KuW commands for details.
Label Formatting Mode
Label Formatting Mode utilizes the current printer configuration to process all reading,
writing, and exception processing for each tag printed. (For exception processing and fault
handling; see the <STX>KcFH command.) The specification for RFID programming is
contained in the data fields of the DPL label format, which instructs the printer to write and
read data. Two Label Formatting Modes for RFID are available. While each supports auto
increment and decrement commands for numeric (+/-), alphanumeric (>/<), or
hexadecimal ((/)) data, they differ when a byte count specifier is added. Both RFID Label
Formatting commands are detailed below.

Up to six RFID operations per label are allowed.
Wx / W1x: RFID
Syntax for RFID (spaces added for readability):
a bbb c d eee ffff gggg jj…j
Where:

Datamax E-Class Mark II Specifications

General

Resolution	203 dpi (8 dots/mm) or 300 dpi (12 dots/mm)
Operating Temperature	40°F to 95°F (4°C to 35°C)
Storage Temperature	-40°F to 140°F (-40°C to 60°C)
Print Method	Direct Thermal / Thermal Transfer
Max Print Speed	6 inches per second (ips)
Memory	8 MB DRAM
Interface	Serial, Parallel, USB
Media Type	Labels, Tags, Receipts
Media Width	0.75" (19 mm) to 4.65" (118 mm)
Media Thickness	0.0025 to 0.008 inches (0.0635 to 0.2032 mm)
Power Requirements	100-240 VAC, 50-60 Hz
