198 Network
2. Type "http://machine's IP address" in your browser's address bar (where "machine's IP address" is the machine's
IP address).
For example: http://192.168.1.2
NOTE: If you are using a Domain Name System or enable a NetBIOS name, you can type another name, such as
"SharedPrinter" instead of the IP address.
• For example:
http://SharedPrinter
If you enable a NetBIOS name, you can also use the node name.
• For example:
http://DELL000499
The NetBIOS name can be found in the Network Configuration Report.
NOTE: For Macintosh, access Web Based Management by clicking the machine's icon on the Status Monitor
screen.
3. No password is required by default. Type a password if you have set one, and then click
.
You can now change the print server settings.
If you have changed the protocol settings, you must restart the machine after clicking Submit to activate the
configuration.
Set a Logon Password for Web Based Management
We recommend setting a logon password to prevent unauthorized access to Web Based Management.
1. Start your web browser.
2. Type "http://machine's IP address" in your browser's address bar (where "machine's IP address" is the machine's
IP address).
For example: http://192.168.1.2
NOTE: If you are using a Domain Name System or enable a NetBIOS name, you can type another name, such as
"SharedPrinter" instead of the IP address.
• For example:
http://SharedPrinter
If you enable a NetBIOS name, you can also use the node name.
• For example:
http://DELL000499
The NetBIOS name can be found in the Network Configuration Report.
NOTE: For Macintosh, access Web Based Management by clicking the machine's icon on the Status Monitor
screen.
3. No password is required by default. Type a password if you have set one, and then click
.
4. Click Administrator.
5. Type the password you want to use (up to 32 characters).
6. Retype the password in the Confirm New Password box.
