Dell E515dn User Manual

277Troubleshooting
Error and Maintenance Messages
As with any sophisticated office product, errors may occur and supply items may have to be replaced. If this happens,
your machine identifies the error or required routine maintenance and shows the appropriate message. The most
common error and maintenance messages are shown in the table.
Follow the instructions in the Actions to improve the status.
Error Message Cause Action
2-sided Disabled
The back cover of the machine is
not closed completely.
Close the back cover of the machine until it locks in the
closed position.
The 2-sided tray is not installed
completely.
Install the 2-sided tray firmly in the machine.
Cartridge Error
Put the Toner
Cartridge back in
The toner cartridge is not installed
correctly.
Pull out the drum unit and toner cartridge assembly, take
out the toner cartridge, and put it back in the drum unit
again. Put the drum unit and toner cartridge assembly
back in the machine.
If the problem continues, contact Dell Customer Service
or your local Dell dealer.
Comm. Error
Poor telephone line quality caused a
communication error.
Send the fax again or connect the machine to another
telephone line. If the problem continues, contact the
telephone company and ask them to check your telephone
line.
Cover is Open.
The front cover is not completely
closed.
Open and then firmly close the front cover of the machine.
The fusing unit cover is not
completely closed or paper was
jammed in the back of the machine
when you turned on the power.
Close the fusing unit cover located inside the back cover of
the machine.
The ADF cover is not completely
closed.
Close the ADF cover of the machine.
If the error message remains, press, Cancel.
Disconnected
The other person or other person's
fax machine stopped the call.
Try to send or receive again.
If calls are stopped repeatedly and you are using a VoIP
(Voice over IP) system, try changing the Compatibility to
Basic (for VoIP).
Document Jam
The document was not inserted
or fed correctly, or the document
scanned from the ADF was too
long.
Remove the jammed paper from the ADF unit.
Clear any debris or scraps of paper from the ADF unit
paper path.
Press Cancel.
DR Mode in Use
The machine is set to Distinctive
Ring mode. You cannot change
the Receive Mode from Manual to
another mode.
Set Distinctive Ring to Off.

Dell E515dn Specifications

General

Duplex printing	Yes
Print technology	Laser
Maximum resolution	600 x 600 DPI
Time to first page (black, normal)	8.5 s
Print speed (black, normal quality, A4/US Letter)	26 ppm
Duplex print speed (black, normal quality, A4/US Letter)	13 ppm
Copier resize	25 - 400 %
Maximum number of copies	99 copies
Copy speed (black, normal quality, A4)	19 cpm
Scan to	File, FTP
Scanner type	Flatbed & ADF scanner
Input color depth	24 bit
Output color depth	8 bit
Scan speed (black)	17 ppm
Scan speed (color)	6 ppm
Image formats supported	BMP, JPG, TIF
Maximum scan resolution	19200 x 19200 DPI
Document formats supported	PDF, XPS
Optical scanning resolution	600 x 1200 DPI
Faxing	Mono faxing
Fax memory	8 MB
Modem speed	33.6 Kbit/s
Printer fonts	Bitmap, PCL, PostScript
Digital sender	-
Printing colors	Black
Maximum duty cycle	10000 pages per month
Recommended duty cycle	300 - 1000 pages per month
Number of PostScript fonts	66
Number of print cartridges	1
Printer management	Dell Printer Hub, Dell Open Print Driver (OPD), Dell OpenManage Printer Manager v2 (OMPM), Standard Printer MIB
Card reader integrated	No
Sound pressure level (printing)	50 dB
Paper input type	Paper tray
Total input capacity	250 sheets
Total output capacity	100 sheets
Maximum input capacity	251 sheets
Auto document feeder (ADF) input capacity	35 sheets
Envelopes sizes	DL
Duplex media weight	60 - 105 g/m²
Paper tray media types	Bond paper, Envelopes, Labels, Plain paper, Recycled paper, Thick paper
Paper tray media weight	80 - 105 g/m²
ISO A-series sizes (A0...A9)	A4, A5, A6
ISO B-series sizes (B0...B9)	B5
ISO C-series sizes (C0...C9)	C5
Duplex media weight (imperial)	16 - 58 lbs
Maximum ISO A-series paper size	A4
Paper tray media weight (imperial)	28 - 43 lbs
Display	LCD
Market positioning	Home & office
Display number of lines	2 lines
Cabling technology	10/100Base-T(X)
Ethernet LAN data rates	10, 100 Mbit/s
Mobile printing technologies	Apple AirPrint, Dell Mobile Print, Google Cloud Print, Mopria Print Service
Standard interfaces	USB 2.0
USB 2.0 ports quantity	USB 2.0 ports have a data transmission speed of 480 Mbps, and are backwards compatible with USB 1.1 ports. You can connect all kinds of peripheral devices to them.
AC input voltage	110 - 240 V
AC input frequency	50 - 60 Hz
Power consumption (off)	5.8 W
Power consumption (standby)	60 W
Power consumption (average operating)	480 W
Server operating systems supported	Windows Server 2003, Windows Server 2003 x64, Windows Server 2008, Windows Server 2008 R2, Windows Server 2012, Windows Server 2012 R2
Sustainability certificates	RoHS, ENERGY STAR
Certification	WEEE, REACH, ErP Lot 4; ErP Lot 6 and 26, Blue Angel Certified, EN 60950-1/IEC 60950-1, EN 55022 (Class B); EN55024; EN61000-3-2 (Class A); EN 61000-3-3; CE Mark (EU); UL 60950-1 / CAN/CSA-C22.2 No. 60950-1-07; ICES-003 (Canada; US CFR Title 47, FCC Part 2 and 15B, Part 15C and Part 68; FDA/DHHS (21CFR, Chapter 1, Subchapter J; RCM (Australia); Telepermit (New Zealand); SABS/ICASA (South Africa); NOM NYCE (Mexico); GS Mark (Germany)
Package depth	517 mm
Package width	623 mm
Package height	499 mm
Package weight	15600 g
Operating altitude	0 - 2000 m
Storage temperature (T-T)	0 - 35 °C
Operating temperature (T-T)	10 - 32.5 °C
Storage relative humidity (H-H)	10 - 80 %
Operating relative humidity (H-H)	20 - 85 %

Weight and Dimensions

Depth	398.5 mm
Width	409 mm
Height	316.5 mm
