199Network
7. Click Submit.
In the future, every time you access Web Based Management, type the password in the Login box, and then click
.
After configuring the settings, log off by clicking .
NOTE: If you are not setting a logon password, you can also set a password by clicking the Please configure the
password button on the machine's web page.
Locate the Machine’s Network Settings
You can change your machine's network settings (IP address, subnet mask, gateway and others) using the control
panel or Web Based Management.
• Locate Network Settings When Using the Dell Control Panel
• Locate Network Settings When Using Web Based Management
Locate Network Settings When Using the Dell Control Panel
1. Press Menu.
2. Press p or q to select the Network option, and then press OK.
3. Proceed to the menu selections you want to configure.
Locate Network Settings When Using Web Based Management
1. Start your web browser.
2. Type "http://machine's IP address" in your browser's address bar (where "machine's IP address" is the machine's
IP address).
For example: http://192.168.1.2
NOTE: If you are using a Domain Name System or enable a NetBIOS name, you can type another name, such as
"SharedPrinter" instead of the IP address.
• For example:
http://SharedPrinter
If you enable a NetBIOS name, you can also use the node name.
• For example:
http://DELL000499
The NetBIOS name can be found in the Network Configuration Report.
NOTE: For Macintosh, access Web Based Management by clicking the machine's icon on the Status Monitor
screen.
3. No password is required by default. Type a password if you have set one, and then click
.
You can change the network settings.
If you change the protocol settings, restart the machine after clicking Submit to activate the configuration.

Dell E515dn Specifications

General

Duplex printing	Yes
Print technology	Laser
Maximum resolution	600 x 600 DPI
Time to first page (black, normal)	8.5 s
Print speed (black, normal quality, A4/US Letter)	26 ppm
Duplex print speed (black, normal quality, A4/US Letter)	13 ppm
Copier resize	25 - 400 %
Maximum number of copies	99 copies
Copy speed (black, normal quality, A4)	19 cpm
Scan to	File, FTP
Scanner type	Flatbed & ADF scanner
Input color depth	24 bit
Output color depth	8 bit
Scan speed (black)	17 ppm
Scan speed (color)	6 ppm
Image formats supported	BMP, JPG, TIF
Maximum scan resolution	19200 x 19200 DPI
Document formats supported	PDF, XPS
Optical scanning resolution	600 x 1200 DPI
Faxing	Mono faxing
Fax memory	8 MB
Modem speed	33.6 Kbit/s
Printer fonts	Bitmap, PCL, PostScript
Digital sender	-
Printing colors	Black
Maximum duty cycle	10000 pages per month
Recommended duty cycle	300 - 1000 pages per month
Number of PostScript fonts	66
Number of print cartridges	1
Printer management	Dell Printer Hub, Dell Open Print Driver (OPD), Dell OpenManage Printer Manager v2 (OMPM), Standard Printer MIB
Card reader integrated	No
Sound pressure level (printing)	50 dB
Paper input type	Paper tray
Total input capacity	250 sheets
Total output capacity	100 sheets
Maximum input capacity	251 sheets
Auto document feeder (ADF) input capacity	35 sheets
Envelopes sizes	DL
Duplex media weight	60 - 105 g/m²
Paper tray media types	Bond paper, Envelopes, Labels, Plain paper, Recycled paper, Thick paper
Paper tray media weight	80 - 105 g/m²
ISO A-series sizes (A0...A9)	A4, A5, A6
ISO B-series sizes (B0...B9)	B5
ISO C-series sizes (C0...C9)	C5
Duplex media weight (imperial)	16 - 58 lbs
Maximum ISO A-series paper size	A4
Paper tray media weight (imperial)	28 - 43 lbs
Display	LCD
Market positioning	Home & office
Display number of lines	2 lines
Cabling technology	10/100Base-T(X)
Ethernet LAN data rates	10, 100 Mbit/s
Mobile printing technologies	Apple AirPrint, Dell Mobile Print, Google Cloud Print, Mopria Print Service
Standard interfaces	USB 2.0
USB 2.0 ports quantity	USB 2.0 ports have a data transmission speed of 480 Mbps, and are backwards compatible with USB 1.1 ports. You can connect all kinds of peripheral devices to them.
AC input voltage	110 - 240 V
AC input frequency	50 - 60 Hz
Power consumption (off)	5.8 W
Power consumption (standby)	60 W
Power consumption (average operating)	480 W
Server operating systems supported	Windows Server 2003, Windows Server 2003 x64, Windows Server 2008, Windows Server 2008 R2, Windows Server 2012, Windows Server 2012 R2
Sustainability certificates	RoHS, ENERGY STAR
Certification	WEEE, REACH, ErP Lot 4; ErP Lot 6 and 26, Blue Angel Certified, EN 60950-1/IEC 60950-1, EN 55022 (Class B); EN55024; EN61000-3-2 (Class A); EN 61000-3-3; CE Mark (EU); UL 60950-1 / CAN/CSA-C22.2 No. 60950-1-07; ICES-003 (Canada; US CFR Title 47, FCC Part 2 and 15B, Part 15C and Part 68; FDA/DHHS (21CFR, Chapter 1, Subchapter J; RCM (Australia); Telepermit (New Zealand); SABS/ICASA (South Africa); NOM NYCE (Mexico); GS Mark (Germany)
Package depth	517 mm
Package width	623 mm
Package height	499 mm
Package weight	15600 g
Operating altitude	0 - 2000 m
Storage temperature (T-T)	0 - 35 °C
Operating temperature (T-T)	10 - 32.5 °C
Storage relative humidity (H-H)	10 - 80 %
Operating relative humidity (H-H)	20 - 85 %

Weight and Dimensions

Depth	398.5 mm
Width	409 mm
Height	316.5 mm
