Page #216 background image
216 Network
authentication with the SNTP time server. (This is not the time displayed on the machine's LCD.) You can
automatically or manually synchronize the machine's time with the Coordinated Universal Time (UTC) provided
by the SNTP time server.
Print the Network Configuration Report
The Network Configuration Report lists the current network configuration, including the network print server
settings.
NOTE: Node Name: The Node Name appears on the current Network Conguration Report. The default Node Name is
"DELLxxxxxx" (where "xxxxxx" is your machine's MAC Address / Ethernet Address.)
NOTE: If the IP Address on the Network Configuration Report shows 0.0.0.0, wait for one minute and try printing it
again.
NOTE: You can find your machine's settings, such as IP address, subnet mask, node name, and MAC Address on the
report, for example:
• IP address: 192.168.0.5
• Subnet mask: 255.255.255.0
• Node name: DELL000499
• MAC Address: 00-0c-a0-00-04-99
1. Press Menu.
2. Do one of the following:
• Dell E515dn/E515dw
Press p or q to display the Print Reports option, and then press OK.
• Dell E514dw
Press p or q to display the Machine Info. option, and then press OK.
3. Press p or q to select the Network Cong option, and then press OK.
4. Press Start.
Configure Your Mail Server Settings Using Web Based Management
Use Web Based Management to configure your Dell machine to connect with your mail server.
1. Start your web browser.
2. Type "http://machine's IP address" in your browser's address bar (where "machine's IP address" is the machine's
IP address).
For example: http://192.168.1.2
3. No password is required by default. Type a password if you have set one, and then click
.
4. Click the Network tab.
5. Click Protocol in the left navigation bar.
6. In the POP3/IMAP4/SMTP field, click Advanced Setting and make sure the Status is Enabled.

Table of Contents

Other manuals for Dell E515dn

Questions and Answers:

Question and Answer IconNeed help?

Do you have a question about the Dell E515dn and is the answer not in the manual?

Dell E515dn Specifications

General IconGeneral
Duplex printingYes
Print technologyLaser
Maximum resolution600 x 600 DPI
Time to first page (black, normal)8.5 s
Print speed (black, normal quality, A4/US Letter)26 ppm
Duplex print speed (black, normal quality, A4/US Letter)13 ppm
Copier resize25 - 400 %
Maximum number of copies99 copies
Copy speed (black, normal quality, A4)19 cpm
Scan toFile, FTP
Scanner typeFlatbed & ADF scanner
Input color depth24 bit
Output color depth8 bit
Scan speed (black)17 ppm
Scan speed (color)6 ppm
Image formats supportedBMP, JPG, TIF
Maximum scan resolution19200 x 19200 DPI
Document formats supportedPDF, XPS
Optical scanning resolution600 x 1200 DPI
FaxingMono faxing
Fax memory8 MB
Modem speed33.6 Kbit/s
Printer fontsBitmap, PCL, PostScript
Digital sender-
Printing colorsBlack
Maximum duty cycle10000 pages per month
Recommended duty cycle300 - 1000 pages per month
Number of PostScript fonts66
Number of print cartridges1
Printer managementDell Printer Hub, Dell Open Print Driver (OPD), Dell OpenManage Printer Manager v2 (OMPM), Standard Printer MIB
Card reader integratedNo
Sound pressure level (printing)50 dB
Paper input typePaper tray
Total input capacity250 sheets
Total output capacity100 sheets
Maximum input capacity251 sheets
Auto document feeder (ADF) input capacity35 sheets
Envelopes sizesDL
Duplex media weight60 - 105 g/m²
Paper tray media typesBond paper, Envelopes, Labels, Plain paper, Recycled paper, Thick paper
Paper tray media weight80 - 105 g/m²
ISO A-series sizes (A0...A9)A4, A5, A6
ISO B-series sizes (B0...B9)B5
ISO C-series sizes (C0...C9)C5
Duplex media weight (imperial)16 - 58 lbs
Maximum ISO A-series paper sizeA4
Paper tray media weight (imperial)28 - 43 lbs
DisplayLCD
Market positioningHome & office
Display number of lines2 lines
Cabling technology10/100Base-T(X)
Ethernet LAN data rates10, 100 Mbit/s
Mobile printing technologiesApple AirPrint, Dell Mobile Print, Google Cloud Print, Mopria Print Service
Standard interfacesUSB 2.0
USB 2.0 ports quantityUSB 2.0 ports have a data transmission speed of 480 Mbps, and are backwards compatible with USB 1.1 ports. You can connect all kinds of peripheral devices to them.
AC input voltage110 - 240 V
AC input frequency50 - 60 Hz
Power consumption (off)5.8 W
Power consumption (standby)60 W
Power consumption (average operating)480 W
Server operating systems supportedWindows Server 2003, Windows Server 2003 x64, Windows Server 2008, Windows Server 2008 R2, Windows Server 2012, Windows Server 2012 R2
Sustainability certificatesRoHS, ENERGY STAR
CertificationWEEE, REACH, ErP Lot 4; ErP Lot 6 and 26, Blue Angel Certified, EN 60950-1/IEC 60950-1, EN 55022 (Class B); EN55024; EN61000-3-2 (Class A); EN 61000-3-3; CE Mark (EU); UL 60950-1 / CAN/CSA-C22.2 No. 60950-1-07; ICES-003 (Canada; US CFR Title 47, FCC Part 2 and 15B, Part 15C and Part 68; FDA/DHHS (21CFR, Chapter 1, Subchapter J; RCM (Australia); Telepermit (New Zealand); SABS/ICASA (South Africa); NOM NYCE (Mexico); GS Mark (Germany)
Package depth517 mm
Package width623 mm
Package height499 mm
Package weight15600 g
Operating altitude0 - 2000 m
Storage temperature (T-T)0 - 35 °C
Operating temperature (T-T)10 - 32.5 °C
Storage relative humidity (H-H)10 - 80 %
Operating relative humidity (H-H)20 - 85 %
Weight and Dimensions IconWeight and Dimensions
Depth398.5 mm
Width409 mm
Height316.5 mm
