234 Network
1. Turn on your machine.
2. Enable your machine's Wi-Fi Direct feature.
3. Move your mouse to the lower right corner of your desktop. When the menu bar appears, click Settings >
Control Panel > Hardware and Sound > Devices and Printers > Add a device.
4. Select your machine.
NOTE: If your computer displays a dialog box that requires the WPS PIN, type the PIN displayed on your Dell
machine's LCD, and then click Next.
5. Select the Wi-Fi Direct push button menu on your machine.
6. When your machine appears in the Devices and Printers dialog box, the wireless configuration and the printer
driver installation are successfully completed.
Available Services
When you want your computer to print to the Dell print server, you must use a resource, also known as a 'service.'
The Dell print server provides these predefined services:
Service (Example) Definition
BINARY_P1 TCP/IP binary
TEXT_P1 TCP/IP text service (adds carriage return after each line feed)
PCL_P1 PCL service (switches PJL-compatible machine to PCL mode)
DELLxxxxxx*
1
TCP/IP binary
DELLxxxxxx_AT*
1
PostScript
®
service for Macintosh
POSTSCRIPT_P1 PostScript
®
service (switches PJL-compatible machine to PostScript
®
mode)
*1: Where "xxxxxx" is the first six digits of your machine's MAC Address (Ethernet Address).
Other Ways to Configure the IP Address
• Configure the IP Address Using DHCP
• Configure the IP Address Using BOOTP
• Configure the IP Address Using RARP
• Configure the IP Address Using APIPA
• Configure the IP Address Using ARP
Configure the IP Address Using DHCP
The Dynamic Host Configuration Protocol (DHCP) is one of several automated mechanisms for IP address
allocation. If you have a DHCP server on your network, the print server obtains its IP address from the DHCP server
automatically and registers its name with any RFC 1001- and 1002-compliant dynamic name services.
If you do not want your print server configured via DHCP, you must set the Boot Method to Static so that the print
server has a static IP address. This will prevent the print server from trying to obtain an IP address from any of these
systems.
To change the Boot Method, use the machine's control panel Network menu or Web Based Management.

Dell E515dn Specifications

General

Duplex printing	Yes
Print technology	Laser
Maximum resolution	600 x 600 DPI
Time to first page (black, normal)	8.5 s
Print speed (black, normal quality, A4/US Letter)	26 ppm
Duplex print speed (black, normal quality, A4/US Letter)	13 ppm
Copier resize	25 - 400 %
Maximum number of copies	99 copies
Copy speed (black, normal quality, A4)	19 cpm
Scan to	File, FTP
Scanner type	Flatbed & ADF scanner
Input color depth	24 bit
Output color depth	8 bit
Scan speed (black)	17 ppm
Scan speed (color)	6 ppm
Image formats supported	BMP, JPG, TIF
Maximum scan resolution	19200 x 19200 DPI
Document formats supported	PDF, XPS
Optical scanning resolution	600 x 1200 DPI
Faxing	Mono faxing
Fax memory	8 MB
Modem speed	33.6 Kbit/s
Printer fonts	Bitmap, PCL, PostScript
Digital sender	-
Printing colors	Black
Maximum duty cycle	10000 pages per month
Recommended duty cycle	300 - 1000 pages per month
Number of PostScript fonts	66
Number of print cartridges	1
Printer management	Dell Printer Hub, Dell Open Print Driver (OPD), Dell OpenManage Printer Manager v2 (OMPM), Standard Printer MIB
Card reader integrated	No
Sound pressure level (printing)	50 dB
Paper input type	Paper tray
Total input capacity	250 sheets
Total output capacity	100 sheets
Maximum input capacity	251 sheets
Auto document feeder (ADF) input capacity	35 sheets
Envelopes sizes	DL
Duplex media weight	60 - 105 g/m²
Paper tray media types	Bond paper, Envelopes, Labels, Plain paper, Recycled paper, Thick paper
Paper tray media weight	80 - 105 g/m²
ISO A-series sizes (A0...A9)	A4, A5, A6
ISO B-series sizes (B0...B9)	B5
ISO C-series sizes (C0...C9)	C5
Duplex media weight (imperial)	16 - 58 lbs
Maximum ISO A-series paper size	A4
Paper tray media weight (imperial)	28 - 43 lbs
Display	LCD
Market positioning	Home & office
Display number of lines	2 lines
Cabling technology	10/100Base-T(X)
Ethernet LAN data rates	10, 100 Mbit/s
Mobile printing technologies	Apple AirPrint, Dell Mobile Print, Google Cloud Print, Mopria Print Service
Standard interfaces	USB 2.0
USB 2.0 ports quantity	USB 2.0 ports have a data transmission speed of 480 Mbps, and are backwards compatible with USB 1.1 ports. You can connect all kinds of peripheral devices to them.
AC input voltage	110 - 240 V
AC input frequency	50 - 60 Hz
Power consumption (off)	5.8 W
Power consumption (standby)	60 W
Power consumption (average operating)	480 W
Server operating systems supported	Windows Server 2003, Windows Server 2003 x64, Windows Server 2008, Windows Server 2008 R2, Windows Server 2012, Windows Server 2012 R2
Sustainability certificates	RoHS, ENERGY STAR
Certification	WEEE, REACH, ErP Lot 4; ErP Lot 6 and 26, Blue Angel Certified, EN 60950-1/IEC 60950-1, EN 55022 (Class B); EN55024; EN61000-3-2 (Class A); EN 61000-3-3; CE Mark (EU); UL 60950-1 / CAN/CSA-C22.2 No. 60950-1-07; ICES-003 (Canada; US CFR Title 47, FCC Part 2 and 15B, Part 15C and Part 68; FDA/DHHS (21CFR, Chapter 1, Subchapter J; RCM (Australia); Telepermit (New Zealand); SABS/ICASA (South Africa); NOM NYCE (Mexico); GS Mark (Germany)
Package depth	517 mm
Package width	623 mm
Package height	499 mm
Package weight	15600 g
Operating altitude	0 - 2000 m
Storage temperature (T-T)	0 - 35 °C
Operating temperature (T-T)	10 - 32.5 °C
Storage relative humidity (H-H)	10 - 80 %
Operating relative humidity (H-H)	20 - 85 %

Weight and Dimensions

Depth	398.5 mm
Width	409 mm
Height	316.5 mm
