Dell PowerEdge R660 - Rear drive module; Removing the rear drive module

NOTE: The numbers on the image do not depict the exact steps. The numbers are for representation of sequence.
Figure 122. Installing the PERC battery
Next steps
1. If removed, install the air shroud.
2. Install the drive backplane cover.
3. Follow the procedure listed in After working inside your system.
Rear drive module
Removing the rear drive module
Prerequisites
1. Follow the safety guidelines listed in the Safety instructions.
2. Follow the procedure listed in Before working inside your system.
3. If installed, remove the air shroud.
4. Remove the rear drives.
5. Disconnect all the cables from the rear drive module.
6. If installed, remove the expansion card riser
Steps
1. Using a Phillips #1 screwdriver, loosen the captive screws on the rear drive module or the liquid cooling rear drive module.
2. Slide the rear drive module forward and then lift it away from the system.
NOTE: The procedure is the same for removing the rear drive module in liquid cooling module configuration.
Installing and removing system components 151
