The following example congures object tracking on the reachability of an IPv6 route:
Dell(conf)#track 105 ipv6 route 1234::/64 reachability
Dell(conf-track-105)#delay down 5
Dell(conf-track-105)#description Headquarters
Dell(conf-track-105)#end
Dell#show track 105
Track 105
IPv6 route 1234::/64 reachability
Description: Headquarters
Reachability is Down (route not in route table)
2 changes, last change 00:03:03
Tracking a Metric Threshold
Use the following commands to congure object tracking on the metric threshold of an IPv4 or IPv6 route.
To remove object tracking, use the no track object-id command.
1 (Optional) Recongure the default resolution value used by the specied protocol to scale the metric for IPv4 or IPv6 routes.
CONFIGURATION mode
track resolution {ip route | ipv6 route} {isis resolution-value | ospf resolution-value}
The range of resolution values is:
• ISIS routes - 1 to 1000. The default is 1.
• OSPF routes - 1 to 1592. The efault is 1.
2 Congure object tracking on the metric of an IPv4 or IPv6 route.
CONFIGURATION mode
track object-id {ip route ip-address/prefix-len | ipv6 route ipv6-address/prefix-len} metric
threshold [vrf vrf-name]
Valid object IDs are from 1 to 500.
Enter an IPv4 address in dotted decimal format. Valid IPv4 prex lengths are from /0 to /32.
Enter an IPv6 address in X:X:X:X::X format. Valid IPv6 prex lengths are from /0 to /128.
(Optional) E-Series only: For an IPv4 route, you can enter a VRF name.
3 (Optional) Congure the time delay used before communicating a change in the UP and/or DOWN status of a tracked route.
OBJECT TRACKING mode
delay {[up seconds] [down seconds]}
Valid delay times are from 0 to 180 seconds.
The default is 0.
4 (Optional) Identify the tracked object with a text description.
OBJECT TRACKING mode
description text
The text string can be up to 80 characters.
5 (Optional) Congure the metric threshold for the UP and/or DOWN routing status to be tracked for the specied route.
OBJECT TRACKING mode
