Codes: * - Default VLAN, G - GVRP VLANs
NUM Status Q Ports
* 1 Active U Gi 1/2
2 Active T Po1(So 0/0-1)
T Gi 1/3
3 Active T Po1(So 0/0-1)
T Gi 1/1
4 Inactive
Dell#conf
Dell(conf)#interface vlan 4
Dell(conf-if-vlan)#
untagged gigabitethernet 1/2
Dell(conf-if-vlan)#show config
!
interface Vlan 4
no ip address
untagged GigabitEthernet 1/2
Dell(conf-if-vlan)#end
Dell#
show vlan
Codes: * - Default VLAN, G - GVRP VLANs
NUM Status Q Ports
* 1 Inactive
2 Active T Po1(So 0/0-1)
T Gi 1/3
3 Active T Po1(So 0/0-1)
T Gi 1/1
4 Active U Gi 1/2
The only way to remove an interface from the Default VLAN is to place the interface in Default mode by using the no switchport
command in INTERFACE mode.
Assigning an IP Address to a VLAN
VLANs are a Layer 2 feature. For two physical interfaces on dierent VLANs to communicate, you must assign an IP address to the VLANs
to route trac between the two interfaces.
The shutdown command in INTERFACE mode does not aect Layer 2 trac on the interface; the shutdown command only prevents
Layer 3 trac from traversing over the interface.
NOTE
: You cannot assign an IP address to the Default VLAN (VLAN 1). To assign another VLAN ID to the Default VLAN, use the
default vlan-id vlan-id command.
In Dell Networking OS, you can place VLANs and other logical interfaces in Layer 3 mode to receive and send routed trac. For more
information, refer to Bulk Conguration.
To assign an IP address, use the following command.
Congure an IP address and mask on the interface.
INTERFACE mode
ip address ip-address mask [secondary]
ip-address mask — Enter an address in dotted-decimal format (A.B.C.D) and the mask must be in slash format (/24).
secondary — This is the interfaces backup IP address. You can congure up to eight secondary IP addresses.
Conguring Native VLANs
Traditionally, ports can be either untagged for membership to one VLAN or tagged for membership to multiple VLANs.
You must connect an untagged port to a VLAN-unaware station (one that does not understand VLAN tags), and you must connect a
tagged port to a VLAN-aware station (one that generates and understands VLAN tags).
876
Virtual LANs (VLANs)
