description description
3 Apply an egress IP ACL to the ACL VLAN group.
CONFIGURATION (conf-acl-vl-grp) mode
ip access-group {group name} out implicit-permit
4 Add VLAN member(s) to an ACL VLAN group.
CONFIGURATION (conf-acl-vl-grp) mode
member vlan {VLAN-range}
5 Display all the ACL VLAN groups or display a specic ACL VLAN group, identied by name.
CONFIGURATION (conf-acl-vl-grp) mode
show acl-vlan-group {group name | detail}
Dell#show acl-vlan-group detail
Group Name :
TestGroupSeventeenTwenty
Egress IP Acl :
SpecialAccessOnlyExpertsAllowed
Vlan Members :
100,200,300
Group Name :
CustomerNumberIdentificationEleven
Egress IP Acl :
AnyEmployeeCustomerElevenGrantedAccess
Vlan Members :
2-10,99
Group Name :
HostGroup
Egress IP Acl :
Group5
Vlan Members :
1,1000
Dell#
Conguring FP Blocks for VLAN Parameters
To allocate the number of FP blocks for the various VLAN processes on the system, use the cam-acl-vlan command. To reset the
number of FP blocks to the default, use the no version of this command. By default, 0 groups are allocated for the ACL in VLAN
contentaware processor (VCAP). ACL VLAN groups or CAM optimization is not enabled by default. You also must allocate the slices for
CAM optimization.
1 Allocate the number of FP blocks for VLAN operations.
CONFIGURATION mode
cam-acl-vlan vlanopenflow <0-2>
2 Allocate the number of FP blocks for ACL VLAN optimization.
CONFIGURATION mode
cam-acl-vlan vlanaclopt <0-2>
3 View the number of FP blocks that is allocated for the dierent VLAN services.
Access Control List (ACL) VLAN Groups and Content Addressable Memory (CAM)
103
