Topics:
IP Access Control Lists (ACLs)
Important Points to Remember
IP Fragment Handling
Congure a Standard IP ACL
Congure an Extended IP ACL
Congure Layer 2 and Layer 3 ACLs
Assign an IP ACL to an Interface
Applying an IP ACL
Congure Ingress ACLs
Congure Egress ACLs
IP Prex Lists
ACL Resequencing
Route Maps
Logging of ACL Processes
Flow-Based Monitoring
IP Access Control Lists (ACLs)
In Dell Networking switch/routers, you can create two dierent types of IP ACLs: standard or extended.
A standard ACL lters packets based on the source IP packet. An extended ACL lters trac based on the following criteria:
IP protocol number
Source IP address
Destination IP address
Source TCP port number
Destination TCP port number
Source UDP port number
Destination UDP port number
For more information about ACL options, refer to the Dell Networking OS Command Reference Guide.
For extended ACL, TCP, and UDP lters, you can match criteria on specic or ranges of TCP or UDP ports. For extended ACL TCP lters,
you can also match criteria on established TCP sessions.
When creating an access list, the sequence of the lters is important. You have a choice of assigning sequence numbers to the lters as
you enter them, or the Dell Networking Operating System (OS) assigns numbers in the order the lters are created. The sequence numbers
are listed in the display output of the show config and show ip accounting access-list commands.
Ingress and egress Hot Lock ACLs allow you to append or delete new rules into an existing ACL (already written into CAM) without
disrupting trac ow. Existing entries in the CAM are shued to accommodate the new entries. Hot lock ACLs are enabled by default and
support both standard and extended ACLs and on all platforms.
NOTE
: Hot lock ACLs are supported for Ingress ACLs only.
108 Access Control Lists (ACLs)
