summary: Displays summary information about a color policy on one or more interfaces.
detail: Displays detailed color policy information on an interface
interface
: Enter the name of the interface that has the color policy congured.
Examples for Displaying a DSCP Color Policy
Display summary information about a color policy for one or more interfaces.
Dell# show qos dscp-color-policy summary
Interface dscp-color-map
GI 1/10 mapONE
GI 1/11 mapTWO
Display summary information about a color policy for a specic interface.
Dell# show qos dscp-color-policy summary gigabitethernet 1/10
Interface dscp-color-map
GI 1/10 mapONE
Display detailed information about a color policy for a specic interface
Dell# show qos dscp-color-policy detail gigabitethernet 1/10
Interface GigabitEthernet 1/10
Dscp-color-map mapONE
yellow 4,7
red 20,30
Enabling QoS Rate Adjustment
By default while rate limiting, policing, and shaping, Dell Networking OS does not include the Preamble, SFD, or the IFG elds. These elds
are overhead; only the elds from MAC destination address to the CRC are used for forwarding and are included in these rate metering
calculations.
The Ethernet packet format consists of:
• Preamble: 7 bytes Preamble
• Start frame delimiter (SFD): 1 byte
• Destination MAC address: 6 bytes
• Source MAC address: 6 bytes
• Ethernet Type/Length: 2 bytes
• Payload: (variable)
• Cyclic redundancy check (CRC): 4 bytes
• Inter-frame gap (IFG): (variable)
You can optionally include overhead elds in rate metering calculations by enabling QoS rate adjustment.
QoS rate adjustment is disabled by default.
• Specify the number of bytes of packet overhead to include in rate limiting, policing, and shaping calculations.
CONFIGURATION mode
qos-rate-adjust overhead-bytes
For example, to include the Preamble and SFD, type qos-rate-adjust 8. For variable length overhead elds, know the number of
bytes you want to include.
The default is disabled.
The range is from 1 to 31.
652
Quality of Service (QoS)
