Interface GigabitEthernet 7/11 ipv6 routing
Description: Austin access point
Track an IPv4/IPv6 Route
You can create an object that tracks the reachability or metric of an IPv4 or IPv6 route.
You specify the route to be tracked by its address and prex-length values. Optionally, for an IPv4 route, you can enter a VRF instance
name if the route is part of a VPN routing and forwarding (VRF) table. The next-hop address is not part of the denition of a tracked IPv4/
IPv6 route.
In order for an route’s reachability or metric to be tracked, the route must appear as an entry in the routing table. A tracked route is
considered to match an entry in the routing table only if the exact IPv4 or IPv6 address and prex length match an entry in the table. For
example, when congured as a tracked route, 10.0.0.0/24 does not match the routing table entry 10.0.0.0/8. Similarly, for an IPv6 address,
3333:100:200:300:400::/80 does not match routing table entry 3333:100:200:300::/64. If no route-table entry has the exact IPv4/IPv6
address and prex length, the tracked route is considered to be DOWN.
In addition to the entry of a route in the routing table, you can congure the UP/DOWN state of a tracked route to be determined in the
following ways:
• By the reachability of the route's next-hop router.
The UP/DOWN state of the route is determined by the entry of the next-hop address in the ARP cache. A tracked route is considered
to be reachable if there is an ARP cache entry for the route's next-hop address. If the next-hop address in the ARP cache ages out for
a route tracked for its reachability, an attempt is made to regenerate the ARP cache entry to see if the next-hop address appears
before considering the route DOWN.
• By comparing the threshold for a route’s metric with current entries in the route table.
The UP/DOWN state of the tracked route is determined by the threshold for the current value of the route metric in the routing table.
To provide a common tracking interface for dierent clients, route metrics are scaled in the range from 0 to 255, where 0 is connected
and 255 is inaccessible. The scaled metric value communicated to a client always considers a lower value to have priority over a higher
value. The resulting scaled value is compared against the congured threshold values to determine the state of a tracked route as
follows:
• If the scaled metric for a route entry is less than or equal to the UP threshold, the state of a route is UP.
• If the scaled metric for a route is greater than or equal to the DOWN threshold or the route is not entered in the routing table, the
state of a route is DOWN.
The UP and DOWN thresholds are user-congurable for each tracked route. The default UP threshold is 254; the default DOWN
threshold is 255. The notication of a change in the state of a tracked object is sent when a metric value crosses a congured
threshold.
The tracking process uses a protocol-specic resolution value to convert the actual metric in the routing table to a scaled metric in the
range from 0 to 255. The resolution value is user-congurable and calculates the scaled metric by dividing a route’s cost by the
resolution value set for the route type:
• For ISIS, you can set the resolution in the range from 1 to 1000, where the default is 10.
• For OSPF, you can set the resolution in the range from 1 to 1592, where the default is 1.
• The resolution value used to map static routes is not congurable. By default, Dell Networking OS assigns a metric of 0 to static
routes.
• The resolution value used to map RIP routes is not congurable. The RIP hop-count is automatically multiplied by 16 to scale it. For
example, a RIP metric of 16 (unreachable) scales to 256, which considers a route to be DOWN.
534
Object Tracking
