The default is 30.
Example of Viewing Congured Server Timeouts
The example shows conguration information for a port for which the authenticator terminates the authentication process for an
unresponsive supplicant or server after 15 seconds.
The bold lines show the new supplicant and server timeouts.
Dell(conf-if-Gi-1/1)#dot1x port-control force-authorized
Dell(conf-if-Gi-1/1)#do show dot1x interface GigabitEthernet 1/1
802.1x information on Gi 1/1:
-----------------------------
Dot1x Status: Enable
Port Control: FORCE_AUTHORIZED
Port Auth Status: UNAUTHORIZED
Re-Authentication: Disable
Untagged VLAN id: None
Guest VLAN: Disable
Guest VLAN id: NONE
Auth-Fail VLAN: Disable
Auth-Fail VLAN id: NONE
Auth-Fail Max-Attempts: NONE
Tx Period: 90 seconds
Quiet Period: 120 seconds
ReAuth Max: 10
Supplicant Timeout: 15 seconds
Server Timeout: 15 seconds
Re-Auth Interval: 7200 seconds
Max-EAP-Req: 10
Auth Type: SINGLE_HOST
Auth PAE State: Initialize
Backend State: Initialize
Enter the tasks the user should do after nishing this task (optional).
Conguring Dynamic VLAN Assignment with Port
Authentication
Dell Networking OS supports dynamic VLAN assignment when using 802.1X.
The basis for VLAN assignment is RADIUS attribute 81, Tunnel-Private-Group-ID. Dynamic VLAN assignment uses the standard dot1x
procedure:
1 The host sends a dot1x packet to the Dell Networking system
2 The system forwards a RADIUS REQEST packet containing the host MAC address and ingress port number
3 The RADIUS server authenticates the request and returns a RADIUS ACCEPT message with the VLAN assignment using Tunnel-
Private-Group-ID
The illustration shows the conguration on the Dell Networking system before connecting the end user device in black and blue text, and
after connecting the device in red text. The blue text corresponds to the preceding numbered steps on dynamic VLAN assignment with
802.1X.
802.1X
97
