The default is 0.
Sample Congurations
Before you set up VRRP, review the following sample congurations.
VRRP for an IPv4 Conguration
The following conguration shows how to enable IPv4 VRRP. This example does not contain comprehensive directions and is intended to
provide guidance for only a typical VRRP conguration. You can copy and paste from the example to your CLI. To support your own IP
addresses, interfaces, names, and so on, be sure that you make the necessary changes. The VRRP topology was created using the CLI
conguration shown in the following example.
Figure 142. VRRP for IPv4 Topology
986
Virtual Router Redundancy Protocol (VRRP)

Dell S3048-ON Specifications

General

Rack Units	1U
Form Factor	Rack-mountable
Input Voltage	100-240V AC
Power Supply	2 hot-swappable power supplies
Management	CLI, Web, SNMP
Product Type	Switch
MAC Address Table Size	32K entries
Jumbo Frame Support	Yes
Latency	< 3 microseconds
Ports	48 x 1GbE RJ45, 4 x 10GbE SFP+
