Chapter 4 Parameters|
Revision August 2008, 03VE, SW V2.04 4-117
07-28  Torque Offset Setting Unit: 0.1
Control
mode
SVC FOCPG TQRPG
Factory Setting: 0.0
Settings 0.0 to 100.0%
 This parameter is torque offset. The motor rated torque is 100%.
07-29  High Torque Offset Unit: 0.1
Control
mode
SVC FOCPG TQRPG
Factory Setting: 30.0
Settings 0.0 to 100.0%
07-30  Middle Torque Offset Unit: 0.1
Control
mode
SVC FOCPG TQRPG
Factory Setting: 20.0
Settings 0.0 to 100.0%
07-31  Low Torque Offset Unit: 0.1
Control
mode
SVC FOCPG TQRPG
Factory Setting: 10.0
Settings 0.0 to 100.0%
 When it is set to 3, the source of torque offset will decide to Pr.07-29, Pr.07-30 and Pr.07-31
by the multi-function input terminals setting (31, 32 or 33). The motor rated torque is 100%.
07-32  Forward Motor Torque Limit Unit: 1
07-33  Forward Regenerative Torque Limit Unit: 1
07-34  Reverse Motor Torque Limit Unit: 1
07-35  Reverse Regenerative Torque Limit Unit: 1
Control
mode
FOCPG TQRPG
Factory Setting: 200
Settings 0 to 500%
 The motor rated torque is 100%. The settings for Pr.07-32 to Pr.07-35 will compare with Pr.03-
00=7, 8, 9, 10. The minimum of the comparison result will be torque limit as shown in the
following figure.
 According to the formula of motor rated torque:
)/(
)(
).(
sradW
P
MNT
ω
=
, where P(ω) is Pr.05-
02 and W(rad/s) is Pr.05-03.
srad
RPM
/
260
=
×
Ï€
