Chapter 4 Parameters|
Revision August 2008, 03VE, SW V2.04 4-79
Group 3 Analog Input/Output Parameters
03-00
Analog Input 1 (AVI)
Factory Setting: 1
03-01 Analog Input 2 (ACI)
Factory Setting: 0
03-02 Analog Input 3 (AUI)
Factory Setting: 0
Control Mode
Settings
VF VFPG SVC FOCPG TQRPG
0: No function
â—‹ â—‹ â—‹ â—‹ â—‹
1: Frequency command (torque limit under TQR control
mode)
â—‹ â—‹ â—‹ â—‹ â—‹
2: torque command (torque limit under speed mode)
â—‹
3: Torque compensation command
â—‹ â—‹ â—‹ â—‹ â—‹
4: PID target value (refer to group 8)
â—‹ â—‹ â—‹ â—‹
5: PID feedback signal (refer to group 8)
â—‹ â—‹ â—‹ â—‹
6: P.T.C. thermistor input value
â—‹ â—‹ â—‹ â—‹ â—‹
7: Positive torque limit
â—‹
8: Negative torque limit
â—‹
9: Regenerative torque limit
â—‹
10: Positive/negative torque limit
â—‹
11: PID feedback signal of tension
â—‹ â—‹ â—‹ â—‹ â—‹
12: Line speed
â—‹ â—‹ â—‹ â—‹ â—‹
13: Reel diameter
â—‹ â—‹ â—‹ â—‹ â—‹
14: PID target value of tension (tension closed-loop)
â—‹ â—‹ â—‹ â—‹ â—‹
15: Tension setting (tension open-loop)
â—‹
16: Zero-speed tension
â—‹
17: Tension taper
â—‹
 When it is frequency command or TQR speed limit, the corresponding value for 0~±
10V/4~20mA is 0 – max. output frequency(Pr.01-00)
 When it is torque command or torque limit, the corresponding value for 0~±10V/4~20mA is 0 –
max. output torque (Pr.07-22).
 When it is torque compensation, the corresponding value for 0~±10V/4~20mA is 0 – rated
torque.
