Chapter 4 Parameters|
Revision August 2008, 03VE, SW V2.04 4-9
Group 3 Analog Input/Output Parameters
Pr. Explanation Settings
Factory
Setting
VF VFPG
SVC
FOCPG
TQRPG
03-00
Analog Input 1 (AVI) 0: No function 1
03-01
Analog Input 2 (ACI) 1: Frequency command (torque limit under TQR control
mode)
0
03-02
Analog Input 3 (AUI) 2: torque command (torque limit under speed mode) 0
3: Torque compensation command
4: PID target value (refer to group 8)
5: PID feedback signal (refer to group 8)
6: P.T.C. thermistor input value
7: Positive torque limit
8: Negative torque limit
9: Regenerative torque limit
10: Positive/negative torque limit
11: PID feedback signal of tension
12: Line speed
13: Reel diameter
14: PID target value of tension (tension closed-loop)
15: Tension setting (tension open-loop)
16: Zero-speed tension
17: Tension taper
03-03
Analog Input Bias 1
(AVI)
-100.0~100.0%
0
03-04
Analog Input Bias 2
(ACI)
-100.0~100.0%
0
03-05
Analog Input Bias 3
(AUI)
-100.0~100.0%
0
03-06
Positive/negative Bias
Mode (AVI)
0
03-07
Positive/negative Bias
Mode (ACI)
0
03-08
Positive/negative Bias
Mode (AUI)
0: Zero bias
1: Lower than bias=bias
2: Greater than bias=bias
3: The absolute value of the bias voltage while serving
as the center
4: Serve bias as the center
0
03-09
Analog Input Gain 1
(AVI)
-500.0~500.0%
100.0
03-10
Analog Input Gain 2
(ACI )
-500.0~500.0%
100.0
03-11
Analog Input Gain 3
(AUI)
-500.0~500.0%
100.0
03-12
ACI/AVI2 Selection 0: ACI
1: AVI 2
0
03-13
Analog Input Delay
Time (AVI)
0.00~2.00 sec
0.01
03-14
Analog Input Delay
Time (ACI)
0.00~2.00 sec
0.01
03-15
Analog Input Delay
Time (AUI)
0.00~2.00 sec
0.01
03-16
Addition Function of
the Analog Input
0: Disable (AVI, ACI, AUI)
1: Enable
03-17
Loss of the ACI Signal 0: Disable
1: Continue operation at the last frequency
2: Decelerate to stop
3: Stop immediately and display E.F.
0
0: Output frequency (Hz)
0
03-18
Analog Output
Selection 1
1: Frequency command (Hz)
2: Motor speed (Hz)
03-21
Analog Output
Selection 2
3: Output current (rms)
4: Output voltage
03-24
Analog Output
Selection 3
5: DC Bus Voltage
6: Power factor
7: Power
8: Output torque
