Delta Electronics AC Motor Drive VFD-VE Series User Manual

Chapter 4 Parameters|
Revision August 2008, 03VE, SW V2.04 4-75
If Pr02-11=1 and Pr02-15=1, Relay 1 RA-RC is open when the drive runs and is closed when
the drive is stopped.
 Bit setting
bit3
MO2
bit2
MO1
bit1
RA
bit0
MRA
Pr02-15
0 0 0 0 0
0 0 0 1 1
0 0 1 0 2
0 0 1 1 3
0 1 0 0 4
0 1 0 1 5
0 1 1 0 6
0 1 1 1 7
1 0 0 0 8
1 0 0 1 9
1 0 1 0 10
1 0 1 1 11
1 1 0 0 12
1 1 0 1 13
1 1 1 0 14
1 1 1 1 15
02-16  Terminal Count Value Unit:1
Control
mode
VF VFPG SVC FOCPG TQRPG
Factory setting: 0
Settings 0 ~ 65535
 The counter trigger can be set by the multi-function terminal MI6 (set Pr.02-06 to 23). Upon
completion of counting, the specified output terminal will be activated (Pr.02-11 to Pr.02-14 is
set to 17).
02-17 Preliminary Count Value Unit:1
Control
mode
VF VFPG SVC FOCPG TQRPG
Factory setting: 0
Settings 0 ~ 65535
 When the counter value reaches this value, the corresponding multi-function output terminal
will be activated, provided one of Pr. 02-11 to 02-14 set to 18 (Preliminary Count Value
Setting). This parameter can be used for the end of the counting to make the drive runs from
the low speed to stop.
