Delta Electronics AC Motor Drive VFD-VE Series - Group 1 Basic Parameters

Chapter 4 Parameters|
4-4 Revision August 2008, 03VE, SW V2.04
Group 1 Basic Parameters
Pr. Explanation Settings
Factory
Setting
VF VFPG SVC FOCPG TQRPG
01-00
Maximum Output
Frequency
50.00~600.00Hz 60.00/
50.00
○ ○ ○ ○ ○
01-01
1st Output Frequency
Setting 1
0.00~600.00Hz 60.00/
50.00
○ ○ ○ ○ ○
01-02
1st Output Voltage
Setting 1
230V: 0.1V~255.0V
460V: 0.1V~510.0V
220.0
440.0
○ ○ ○ ○ ○
01-03
2nd Output Frequency
Setting 1
0.00~600.00Hz 0.50
○ ○
01-04
2nd Output Voltage
Setting 1
230V: 0.1V~255.0V
460V: 0.1V~510.0V
5.0
10.0
○ ○
01-05
3rd Output Frequency
Setting 1
0.00~600.00Hz 0.50
○ ○
01-06
3rd Output Voltage
Setting 1
230V: 0.1V~255.0V
460V: 0.1V~510.0V
5.0
10.0
○ ○
01-07
4th Output Frequency
Setting 1
0.00~600.00Hz 0.00
○ ○ ○ ○
01-08
4th Output Voltage
Setting 1
230V: 0.1V~255.0V
460V: 0.1V~510.0V
0.0
0.0
○ ○ ○
01-09 Start Frequency
0.00~600.00Hz 0.50
○ ○ ○ ○
01-10
Output Frequency Upper
Limit
0.00~600.00Hz
600.00
○ ○ ○ ○
01-11
Output Frequency Lower
Limit
0.00~600.00Hz
0.00
○ ○ ○ ○
01-12
Accel Time 1 0.00~600.00 sec/0.00~6000.0 sec
10.00/
10.0
○ ○ ○ ○
01-13
Decel Time 1 0.00~600.00 sec/0.00~6000.0 sec
10.00/
10.0
○ ○ ○ ○
01-14
Accel Time 2 0.00~600.00 sec/0.00~6000.0 sec
10.00/
10.0
○ ○ ○ ○
01-15
Decel Time 2 0.00~600.00 sec/0.00~6000.0 sec
10.00/
10.0
○ ○ ○ ○
01-16
Accel Time 3 0.00~600.00 sec/0.00~6000.0 sec
10.00/
10.0
○ ○ ○ ○
01-17
Decel Time 3 0.00~600.00 sec/0.00~6000.0 sec
10.00/
10.0
○ ○ ○ ○
01-18
Accel Time 4 0.00~600.00 sec/0.00~6000.0 sec
10.00/
10.0
○ ○ ○ ○
01-19
Decel Time 4
0.00~600.00 sec/0.00~6000.0 sec 10.00/
10.0
○ ○ ○ ○
01-20
JOG Acceleration Time 0.00~600.00 sec/0.00~6000.0 sec
1.00/
1.0
○ ○ ○ ○
01-21
JOG Deceleration Time 0.00~600.00 sec/0.00~6000.0 sec
1.00/
1.0
○ ○ ○ ○
01-22
JOG Frequency
0.00~600.00Hz 6.00
○ ○ ○ ○ ○
01-23
1st/4th Accel/decel
Frequency
0.00~600.00Hz 0.00
○ ○ ○ ○
01-24
S-curve for Acceleration
Departure Time 1
0.00~25.00 sec/0.00~250.0 sec 0.2/0.0
○ ○ ○ ○
01-25
S-curve for Acceleration
Arrival Time 2
0.00~25.00 sec /0.00~250.0 sec 0.2/0.0
○ ○ ○ ○
01-26
S-curve for Deceleration
Departure Time 1
0.00~25.00 sec /0.00~250.0 sec 0.2/0.0
○ ○ ○ ○
01-27
S-curve for Deceleration
Arrival Time 2
0.00~25.00 sec /0.00~250.0 sec 0.2/0.0
○ ○ ○ ○
01-28
Skip Frequency 1 (upper
limit)
0.00~600.00Hz 0.00
○ ○ ○ ○
01-29
Skip Frequency 1 (lower
limit)
0.00~600.00Hz 0.00
○ ○ ○ ○
01-30
Skip Frequency 2 (upper
limit)
0.00~600.00Hz 0.00
○ ○ ○ ○
01-31
Skip Frequency 2 (lower
limit)
0.00~600.00Hz 0.00
○ ○ ○ ○
01-32
Skip Frequency 3 (upper
limit)
0.00~600.00Hz 0.00
○ ○ ○ ○
01-33
Skip Frequency 3 (lower
limit)
0.00~600.00Hz 0.00
○ ○ ○ ○
01-34
Mode Selection when
Frequency < Fmin
0: Output Waiting
1: Zero-speed operation
2: Fmin (4th output frequency setting)
0
○ ○ ○ ○
01-35 1st Output Frequency
0.00~600.00Hz 60.00/
○ ○ ○ ○ ○
