Delta Electronics AC Motor Drive VFD-VE Series - Main Circuit Terminals

Chapter 2 Installation and Wiring|
Revision August 2008, 03VE, SW V2.04 2-9
2.3.2 Main Circuit Terminals
Frame B
+1
+2
B
1
-
B2
U/T1 V/T2 W/T3
Screw Torque :
Wire Gauge :
18Kgf-cm
18~10AWG
R/L1 S/L2 T/L3
Main circuit terminals
R/L1, S/L2, T/L3, U/T1, V/T2, W/T3,
, +1, +2/B1, -, B2
Models Wire Torque Wire Type
VFD007V23A-2
VFD007V43A-2
VFD015V23A-2
VFD015V43A-2
VFD022V23A-2
VFD022V43A-2
VFD037V23A-2
VFD037V43A-2
14-10 AWG
(2.1-5.3mm
2
)
18kgf-cm
(15.6in-lbf)
Stranded
copper only,
75
o
C
Frame C
POWER
IM
MOTOR3
Main circuit terminals
R/L1, S/L2, T/L3, U/T1, V/T2, W/T3,
, +1, +2/B1, -, B2
Models Wire Torque Wire Type
VFD055V23A-2
VFD075V23A-2
VFD110V43B-2
VFD055V43A-2
VFD075V43A-2
12-8 AWG
(3.3-8.4mm
2
)
30kgf-cm
(26in-lbf)
Stranded
copper only,
75
o
C
