Delta Electronics AC Motor Drive VFD-VE Series - Summary of Parameter Settings; Group 0 System Parameters

Chapter 4 Parameters|
4-2 Revision August 2008, 03VE, SW V2.04
4.1 Summary of Parameter Settings
: The parameter can be set during operation.
Group 0 System Parameters
Pr. Explanation Settings
Factory
Setting
VF VFPG SVC FOCPG TQRPG
00-00
Identity Code of the AC
motor drive
Read-only
0
○ ○ ○ ○ ○
00-01
Rated Current Display of
the AC motor drive
Read-only 0
○ ○ ○ ○ ○
00-02
Parameter Reset
0: No function
1: Read only
2: Enable group 11 parameters setting
8: Keypad lock
9: All parameters are reset to factory settings (50Hz,
220V/380V)
10: All parameters are reset to factory settings (60Hz,
220V/440V)
0
○ ○ ○ ○ ○
00-03
Start-up Display Selection
0: Display the frequency command value (LED F)
1: Display the actual output frequency (LED H)
2: Multifunction display, see Pr.00-04 (LED U)
3: Display the output current (A)
0
○ ○ ○ ○ ○
00-04
Content of Multi Function
Display
0: Display output current (A)
1: Display counter value (C)
2: Display output frequency (H)
3: Display DC-BUS voltage (
u
)
4: Display output voltage (E)
5: Output power factor angle (n)
6: Display output power (kW)
7: Display actual motor speed (HU)
8: Display estimate output torque (kg-m)
9: Display PG position (G) (refer to Pr.10-00 and Pr.10-
01)
10: Display PID feedback
11: Display AVI (%)
12: Display ACI (%)
13: Display AUI (%)
14: Display the temperature of heat sink (°C)
15: Display the temperature of IGBT (°C)
16: The status of digital input (ON/OFF)
17: The status of digital output (ON/OFF)
18: Multi-step speed
19: The corresponding CPU pin status of digital input
20: The corresponding CPU pin status of digital output
21: Number of actual motor revolution (PG1 of PG card)
22: Pulse input frequency (PG2 of PG card)
23: Pulse input position (PG2 of PG card)
0
○ ○ ○ ○ ○
00-05
User-Defined Coefficient K
Digit 4: decimal point number (0 to 3)
Digit 0-3: 40 to 9999
0
○ ○ ○ ○ ○
00-06 Software Version Read-only
#.#
○ ○ ○ ○ ○
00-07
Password Input
1 to 9998 and 10000 to 65535
0 to 2: times of wrong password
0
○ ○ ○ ○ ○
00-08
Password Set
1 to 9998 and 10000 to 65535
0: No password set or successful input in Pr.00-07
1: Password has been set
0
○ ○ ○ ○ ○
00-09
Energy Saving Gain
10~1000 % 100%
○
00-10
Control Method
0: V/f Control
1: V/f Control + Encoder (VFPG)
2: Sensorless vector control (SVC)
3: FOC vector control + Encoder (FOCPG)
4: Torque control + Encoder (TQRPG)
0
○ ○ ○ ○ ○
00-11
V/f Curve Selection
0: V/f curve determined by group 01
1: 1.5 power curve
2: Square curve
0
○ ○
00-12
Constant/Variable Torque
Selection
0: Constant Torque (100%)
1: Variable Torque (125%)
0
○ ○ ○ ○
00-13
Optimal
Acceleration/Deceleration
Setting
0: Linear accel./decel. I
1: Auto accel., linear decel.
2: Linear accel., auto decel.
3: Auto accel./decel.
0
○ ○ ○ ○
