Appendix B Accessories|
Revision August 2008, 03VE, SW V2.04 B-21
ABZ1+ PS1 AB2+PS1
Types of Pulse Generators
5V 12V 5V 12V
Line driver
Q
Q
OC
5V
TP
12V
OC
5V
TP
12V
OC
5V
TP
12V
OC
5V
TP
12V
Complementary
O/P
0V
VCC
OC
5V
TP
12V
OC
5V
TP
12V
OC
5V
TP
12V
OC
5V
TP
12V
B.8.2 EMV-PG01O
PG OUT
Pulse output
AB2: PG2 signal
mode switch
ABZ1: PG1 signal
mode switch
PG1
Pulse feedback
PG2
Pulse input
PS1:
5/12V switch
1. Terminals descriptions
Terminal
Symbols
Descriptions
VP
Power source of EMV-PG01O (use PS1 to switch 12V/5V)
Output Voltage: +5V/+12V±5% 200mA
